Specifications

PRICING

Price	Standard
Price - MSRP	4599
Price - Currency	US Dollars
Price - Warranty (Months)	0
Price - Destination Charge	160
Price - MSRP + Destination	4759

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	2-Stroke
Engine - Cooling	Liquid
Engine - Valves	0
Engine - Valves Per Cylinder	0
Engine - Valve Configuration	Reed Valve
Engine - Bore (mm)	52.5
Engine - Bore (in)	2.07
Engine - Stroke (mm)	45.8
Engine - Stroke (in)	1.8
Engine - Displacement (cc)	99
Engine - Displacement (ci)	6
Engine - Compression Ratio	10.2:1
Engine - Starter	Kick
Engine - Fuel Requirements	Regular
Engine - Compression Ratio (Secondary)	8.7:1
Engine - Fuel Type	Gas / Oil Injected
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Carburetion Brand	Keihin
Carburetion - Fuel Injector	No
Carburetion - Carburetor	Yes
Carburetion - Number Of Carburetors	1
Carburetion - Carburetor Size (mm)	38
Carburetion - Carburetion Type	Carburetor
Parental Controls - Speed Governor	No

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	6
Transmission - Overdrive	Yes
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Reverse	No

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	75.6
Dimensions - Length (mm)	1920.2
Dimensions - Width (in)	30.1
Dimensions - Width (mm)	764.5
Dimensions - Height (in)	43.3
Dimensions - Height (mm)	1099.8
Dimensions - Wheelbase (in)	51.6
Dimensions - Wheelbase (mm)	1310.6
Dimensions - Ground Clearance (in)	13
Dimensions - Ground Clearance (mm)	330.2
Dimensions - Length (ft)	6.3
Dimensions - Length (ft/ft)	6
Dimensions - Length (ft/in)	3.6
Weight	Standard
Weight - Wet Weight (lbs)	169.7
Weight - Wet Weight (kg)	77
Capacities	Standard
Capacities - Fuel Capacity (gal)	1.3
Capacities - Fuel Capacity (l)	5
Performance	Standard

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Fork Guards	Yes
Exterior Guards - Saddle Bag Guard	No
Exterior Guards - Belt Guard	No
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Front Fender	Standard
Rear Fender	Standard
Tank Divider - Pocket	No
Stand	Standard
Stand - Stand Type	Kick
Handlebars	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Inverted Fork
Front Suspension - Front Suspension Size (in)	1.4
Front Suspension - Front Suspension Size (mm)	36
Front Suspension - Front Travel (in)	10.8
Front Suspension - Front Travel (mm)	274.3
Front Suspension - Front Adjustable Fork Pre-Load	No
Front Suspension - Front Adjustable Rebound Damping	Yes
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Steering Damper	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	10.8
Rear Suspension - Rear Travel (mm)	274.3
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	Yes
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Brand Name	UNI-TRAK®
Rear Suspension - Rear Suspension Material	Aluminum
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Aluminum
Wheels - Tube / Tubeless	Tubed
Tires	Standard
Tires - Front Tire Width	70
Tires - Front Tire Aspect Ratio	100
Tires - Front Wheel Diameter	19
Tires - Rear Tire Width	90
Tires - Rear Tire Aspect Ratio	100
Tires - Rear Wheel Diameter	16
Tires - Front Tire (Full Spec)	70/100R 19
Tires - Rear Tire (Full Spec)	90/100R 16

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Rear Brake Type	Disc

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	34.3
Seat Specifications - Seat Height (mm)	871.2
Seat Specifications - Number Of Seats	1
Seat Backrest - Backrest Logo Plate	No
Seat Backrest - Lumbar Adjustment	No
Sidecar - Detachable	No

STORAGE

Hard Side Cases - Number Of Side Cases	0
Saddle Bag(s) - Number Of Saddle Bags	0
Cupholder - Number Of Cupholders	0
Sidecar Storage Cover - Camouflage Trim	No

GLASS

Windshield - Windshield Lowers	No
Windshield - Height Adjustable	No
Windshield - Tinted	No

CONVENIENCE

Heated Hand Grips - Adjustable

No

PAINT & FINISH

Paint	Standard
Paint - Metallic	No
Decal Kit	Standard

AUDIO & COMMUNICATION

Radio - Satellite	No
Speakers - Number Of Speakers	0
CD Player - Number Of Discs	0

STEERING

Steering	Standard
Steering - Steering Control	Handlebar

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
