Specifications

PRICING

Price	Standard
Price - Warranty (Months)	6
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	Single-Cylinder
Engine - Cylinders	1
Engine - Engine Stroke	4-Stroke
Engine - Cooling	Air
Engine - Valves	2
Engine - Valves Per Cylinder	2
Engine - Valve Configuration	SOHC
Engine - Bore (mm)	53
Engine - Bore (in)	2.09
Engine - Stroke (mm)	50.6
Engine - Stroke (in)	1.99
Engine - Displacement (cc)	112
Engine - Displacement (ci)	6.8
Engine - Compression Ratio	9.5:1
Engine - Starter	Electric / Kick
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Carburetion Brand	Keihin
Carburetion - Fuel Injector	No
Carburetion - Carburetor	Yes
Carburetion - Number Of Carburetors	1
Carburetion - Carburetor Size (mm)	18
Carburetion - Carburetion Type	Carburetor
Parental Controls	Standard
Parental Controls - Speed Governor	Yes

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	4
Transmission - Overdrive	No
Transmission - Primary Drive (Rear Wheel)	Chain
Transmission - Reverse	No
Adjustable Throttle	Standard

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	61.4
Dimensions - Length (mm)	1559.6
Dimensions - Width (in)	25.6
Dimensions - Width (mm)	650.2
Dimensions - Height (in)	39
Dimensions - Height (mm)	990.6
Dimensions - Wheelbase (in)	42.3
Dimensions - Wheelbase (mm)	1074.4
Dimensions - Ground Clearance (in)	10.4
Dimensions - Ground Clearance (mm)	264.2
Dimensions - Length (ft)	5.12
Dimensions - Length (ft/ft)	5
Dimensions - Length (ft/in)	1.4
Weight	Standard
Weight - Wet Weight (lbs)	167.5
Weight - Wet Weight (kg)	76
Capacities	Standard
Capacities - Fuel Capacity (gal)	1
Capacities - Fuel Capacity (l)	3.8
Performance	Standard

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Construction - Body Material	Plastic
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Fork Guards	No
Exterior Guards - Saddle Bag Guard	No
Exterior Guards - Belt Guard	No
Exterior Guards - Hand Guards	No
Exterior Guards - Brush Guard	No
Exterior Guards - Exhaust Guard	Yes
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Front Fender	Standard
Rear Fender	Standard
Tank Divider - Pocket	No
Stand	Standard
Stand - Stand Type	Kick
Handlebars	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Telescopic Fork
Front Suspension - Front Suspension Size (in)	1.2
Front Suspension - Front Suspension Size (mm)	30
Front Suspension - Front Travel (in)	5.5
Front Suspension - Front Travel (mm)	139.7
Front Suspension - Front Adjustable Fork Pre-Load	No
Front Suspension - Front Adjustable Rebound Damping	No
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Steering Damper	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	5.2
Rear Suspension - Rear Travel (mm)	132.1
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	No
Rear Suspension - Rear Adjustable Rebound Damping	No
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Material	Steel
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Steel
Wheels - Tube / Tubeless	Tubed
Wheels - Front Wheel Width (in)	2
Wheels - Rear Wheel Width (in)	1.6
Tires	Standard
Tires - Front Wheel Diameter	14
Tires - Rear Wheel Diameter	12
Tires - Front Tire (Full Spec)	2.5 x 14
Tires - Rear Tire (Full Spec)	3.0 x 12

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Drum
Brakes - Front Brake Diameter (in)	3.5
Brakes - Front Brake Diameter (mm)	90
Brakes - Rear Brake Type	Drum
Brakes - Rear Brake Diameter (in)	4.3
Brakes - Rear Brake Diameter (mm)	110

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	28.7
Seat Specifications - Seat Height (mm)	729
Seat Specifications - Number Of Seats	1
Seat Backrest - Backrest Logo Plate	No
Seat Backrest - Lumbar Adjustment	No
Sidecar - Detachable	No

STORAGE

Hard Side Cases - Number Of Side Cases	0
Saddle Bag(s) - Number Of Saddle Bags	0
Cupholder - Number Of Cupholders	0
Sidecar Storage Cover - Camouflage Trim	No

GLASS

Windshield - Windshield Lowers	No
Windshield - Height Adjustable	No

CONVENIENCE

Heated Hand Grips - Adjustable

No

PAINT & FINISH

Paint	Standard
Paint - Metallic	No
Decal Kit	Standard

AUDIO & COMMUNICATION

Radio - Satellite	No
Speakers - Number Of Speakers	0
CD Player - Number Of Discs	0

STEERING

Steering	Standard
Steering - Steering Control	Handlebar
