Specifications

PRICING

Price	Standard
Price - MSRP	8499
Price - Currency	US Dollars
Price - Warranty (Months)	12
Price - Destination Charge	370
Price - MSRP + Destination	8869
Price - Warranty (Condition)	Limited

ENGINE

Engine	Standard
Engine - Engine Type	V Twin
Engine - Cylinders	2
Engine - Engine Stroke	4-Stroke
Engine - Horsepower (bhp)	50
Engine - Horsepower (kW)	37
Engine - Horsepower RPM	5700
Engine - Torque (Ft Lbs)	58.2
Engine - Torque (Nm)	78.9
Engine - Torque RPM	3500
Engine - Cooling	Liquid / Air
Engine - Valves	8
Engine - Valves Per Cylinder	4
Engine - Valve Configuration	SOHC
Engine - Bore (mm)	88
Engine - Bore (in)	3.47
Engine - Stroke (mm)	74.2
Engine - Stroke (in)	2.92
Engine - Displacement (cc)	903
Engine - Displacement (ci)	55.1
Engine - Compression Ratio	9.5:1
Engine - Starter	Electric
Engine - Fuel Requirements	Regular
Engine - Fuel Type	Gas
Engine - Turbocharged	No
Engine - Supercharged	No
Carburetion	Standard
Carburetion - Carburetion Brand	Keihin
Carburetion - Fuel Injector	Yes
Carburetion - Fuel Injector Size (mm)	34
Carburetion - Carburetor	No
Carburetion - Number Of Carburetors	0
Carburetion - Carburetion Type	Fuel Injected
Parental Controls - Speed Governor	No

TRANSMISSION

Transmission	Standard
Transmission - Transmission Type	Manual
Transmission - Number Of Speeds	5
Transmission - Primary Drive (Rear Wheel)	Belt
Transmission - Reverse	No
Heel Toe Shifter	Standard

TECHNICAL SPECIFICATIONS

Dimensions	Standard
Dimensions - Length (in)	94.7
Dimensions - Length (mm)	2405.4
Dimensions - Width (in)	35.2
Dimensions - Width (mm)	894.1
Dimensions - Height (in)	44.1
Dimensions - Height (mm)	1120.1
Dimensions - Wheelbase (in)	64.8
Dimensions - Wheelbase (mm)	1645.9
Dimensions - Ground Clearance (in)	5.5
Dimensions - Ground Clearance (mm)	139.7
Dimensions - Length (ft)	7.89
Dimensions - Length (ft/ft)	7
Dimensions - Length (ft/in)	10.7
Weight	Standard
Weight - Wet Weight (lbs)	610.8
Weight - Wet Weight (kg)	277.1
Capacities	Standard
Capacities - Fuel Capacity (gal)	5.3
Capacities - Fuel Capacity (l)	20.1
Performance	Standard

EXTERIOR

Construction	Standard
Construction - Frame	Steel
Hand Grips	Standard
Foot Pegs	Standard
Foot Pegs - Foot Peg Location	Driver and Passenger
Foot Pegs - Adjustable	No
Exterior Guards	Standard
Exterior Guards - Chain Guard	No
Exterior Guards - Drive Shaft Guard	No
Exterior Guards - Fork Guards	Yes
Exterior Guards - Hand Guards	No
Exterior Guards - Brush Guard	No
Exterior Guards - Heel Guards	No
Exterior Guards - Light Guard	No
Exterior Covers	Standard
Exterior Covers - Side Cover	Yes
Front Fender	Standard
Rear Fender	Standard
Stand	Standard
Stand - Stand Type	Kick
Handlebars	Standard

SUSPENSION

Front Suspension	Standard
Front Suspension - Front Suspension Type	Telescopic Fork
Front Suspension - Front Suspension Size (in)	1.6
Front Suspension - Front Suspension Size (mm)	41
Front Suspension - Front Travel (in)	5.9
Front Suspension - Front Travel (mm)	149.9
Front Suspension - Front Adjustable Fork Pre-Load	No
Front Suspension - Front Adjustable Rebound Damping	No
Front Suspension - Front Central Suspension Strut	No
Front Suspension - Steering Damper	No
Rear Suspension	Standard
Rear Suspension - Rear Suspension Type	Twin Sided Swing Arm
Rear Suspension - Rear Travel (in)	4.1
Rear Suspension - Rear Travel (mm)	104.1
Rear Suspension - Rear Adjustable Shock / Spring Pre-Load	Yes
Rear Suspension - Rear Adjustable Rebound Damping	No
Rear Suspension - Number Rear Shock Absorbers	1
Rear Suspension - Rear Suspension Brand Name	UNI-TRAK®
Rear Suspension - Air Adjustable	No

WHEELS & TIRES

Wheels	Standard
Wheels - Wheels Composition	Steel
Tires	Standard
Tires - Front Tire Width	80
Tires - Front Tire Aspect Ratio	90
Tires - Front Tire Speed Rating	H
Tires - Front Wheel Diameter	21
Tires - Rear Tire Width	180
Tires - Rear Tire Aspect Ratio	70
Tires - Rear Tire Speed Rating	H
Tires - Rear Wheel Diameter	15
Tires - Front Tire (Full Spec)	80/90-21 M/C 48H
Tires - Rear Tire (Full Spec)	180/70-15 M/C 76H

BRAKES

Brakes	Standard
Brakes - Front Brake Type	Hydraulic Disc
Brakes - Front Brake Diameter (in)	11.8
Brakes - Front Brake Diameter (mm)	300
Brakes - Rear Brake Type	Hydraulic Disc
Brakes - Rear Brake Diameter (in)	10.6
Brakes - Rear Brake Diameter (mm)	270

SEATS

Seat	Standard
Seat - Seat Type	One-Piece
Seat - Adjustable	No
Seat - Seat Material	Vinyl
Seat - Seat Location	Driver and Passenger
Seat - Folding	No
Seat Specifications	Standard
Seat Specifications - Seat Height (in)	27
Seat Specifications - Seat Height (mm)	685.8
Seat Specifications - Number Of Seats	2
Grab Rail or Strap	Standard
Sidecar - Detachable	No

INSTRUMENTATION

Digital Instrumentation	Standard
Clock	Standard
Trip Odometer	Standard
Speedometer	Standard
Temperature Warning	Standard
Temperature Warning - Temperature Warning Type	Light
Fuel Level Warning	Standard
Fuel Level Warning - Fuel Level Warning Type	Gauge

STORAGE

Hard Side Cases - Number Of Side Cases	0
Cupholder - Number Of Cupholders	0
Sidecar Storage Cover - Camouflage Trim	No

LIGHTS

Halogen Headlight(s)	Standard
Headlight(s)	Standard
Headlight(s) - Type	Halogen

GLASS

Rearview Mirrors

Standard

CONVENIENCE

Heated Hand Grips - Adjustable

No

PAINT & FINISH

Paint	Standard
Paint - Metallic	Yes

AUDIO & COMMUNICATION

Radio - Satellite	No
Speakers - Number Of Speakers	0
CD Player - Number Of Discs	0

STEERING

Steering	Standard
Steering - Steering Control	Handlebar
